KP-532 80mm Kiosk Printer Module , Embedded Thermal Printer For Self Service Machines

Place of Origin : Xiamen

Brand Name : GOOJPRT

Model Number : 80mm Driver boad

MOQ : 1

Price : Negotiated

Payment Terms : T/T, Western Union

Certification : CE/ROSH/FCC

Packaging Details : Carton

Delivery Time : 5day shipping

Supply Ability : 50000pcs/month

Contact Now

KP-532 80mm thermal kiosk embedded printer for self-service machines




Benefit:

80mm printer could support for 2inch or 3inch paper width printing,it is use for in wide range of applications.

Feature:

  1. Double QR CODE printing
  2. Reliable printing mechanism
  3. High printing speed 150mm/s
  4. near paper end sensor

Application:

  1. Parking payment terminal
  2. Gaming machine
  3. ATMs & Banking machine
  4. Gas station
  5. medical treatment equipment

Specification:





Print Method Line thermal printer
Paper Width 80mm
Printing Width 72mm
Resolution 203DPI
Resolution Ration 576 dots
Printing Speed 200mm/s
Printing Content ASCII CH(8x16,9x17,9x24,12×24,); GBK(16x16,24×24),One-dimension Bar Code ,support printing different dot diagram and download bitmap.extensible two-dimension bar code.
Font 9X17(ASCII),24x24(Chinese)



Type KP-532
Printing Print method: Thermal dot line
Number of dots/line: 576
Resolution: 8(dots/mm)
Speed(mm/s) Max. 150(24VDC)
Printing width: 80mm
Paper Paper width (mm): 80
Max. paper thickness (μ): 80
Paper supply method: Straight ahead
Paper feed precision: 0.125mm

Interface:Parallel+Serial+USB
Detection Paper detection: Opto sensor
Head temperature detect: Thermistor
Rubber ruller detection: With

Character:Font A:12x24(Including 2-dot horizontal spacing)
Font B:9x17(Including 2-dot horizontal spacing)
Power supply Drive voltage: 24±10%
Logical voltage: 3.0-5.5
Reliability printer head:150km/100M pulses
Auto-Cutter: 1,000,000cuts
Operating temperature (C°): 0~50
Operating humidity(%): 20~85
Dimensions (WxDxH mm): 270x179x142
Weight (g): 2000
Compatible Model: EPSON M-T532AF/AP
